Galvanometer
As one of the most important components of laser equipment, there are various types of galvanometers to meet different processing and production requirements.
For product pricing, customization, or other inquiries:
Description
What Is the Galvanometer?
Traditionally, the 2D galvanometer is the most common model for flat marking. The 3D galvanometer is mainly used for relief engraving and deep engraving. 2.5D galvanometer is used for large format marking applications.
The situation becomes flexible with different control ways. 2D galvanometer can also be used for relief engraving and deep engraving. Our company provides customized solutions according to your needs and recommendations are one of our pre-sales services.
| Model | Parameter | |
| Sino Galvo Brand: RC10012D scanning head, economic model for common application. | Marking Speed 4000mm/s Marking speed: 4000mm/s Positioning speed: 8000mm/s Writing speed: 559cps Step response time (full stroke 1%): 260us Step response time (full stroke 10%): 830us Tracking error: ≤144us Accuracy and error Linearity: 99.9% Repeatable positioning accuracy:＜8μRad. Gain error:＜5mRad. Zero offset (batch origin error): ＜5mRad. Long-term drift (continuous operation for 8 hours): ＜0.5mRad. Proportional drift: ＜40PPM/℃ Zero drift:＜15μRad./℃ |  |
| Sino Galvo Brand: RC7110 | Marking speed: 5000mm/s Positioning speed: 8000mm/s Writing speed: 450cps Step response time (full stroke 1%): 350us Step response time (full stroke 10%): 750us Tracking error: ≤164us Accuracy and error Linearity: 99.9% Repeatable positioning accuracy:＜8μRad. Gain error:＜5mRad. Zero offset (batch origin error): ＜5mRad. Long-term drift (continuous operation for 8 hours): ＜0.5mRad. Proportional drift: ＜40PPM/℃ Zero drift:＜15μRad./℃ |  |
| Sino Galvo Brand: RC7210 | Marking speed: 8000mm/s Positioning speed: 15000mm/s Writing speed: 559cps Step response time (full stroke 1%): 260us Step response time (full stroke 10%): 830us Tracking error: ≤144us Accuracy and error Linearity: 99.9% Repeatable positioning accuracy:＜8μRad. Gain error:＜5mRad. Zero offset (batch origin error): ＜5mRad. Long-term drift (continuous operation for 8 hours): ＜0.5mRad. Proportional drift: ＜40PPM/℃ Zero drift:＜15μRad./℃ |  |
| Sino Galvo Brand: AF2206Auto Focus Function | Marking speed: 8000mm/s Positioning speed: 15000mm/s Writing speed: 559cps Step response time (full stroke 1%): 260us Step response time (full stroke 10%): 830us Tracking error: ≤144us Accuracy and error Linearity: 99.9% Repeatable positioning accuracy:＜8μRad. Gain error:＜5mRad. Zero offset (batch origin error): ＜5mRad. Long-term drift (continuous operation for 8 hours): ＜0.5mRad. Proportional drift: ＜40PPM/℃ Zero drift:＜15μRad./℃ |  |
| Sino Galvo Brand: FL7210-3D3D model, used for deep engraving and relief engraving. | Marking speed: 6000mm/s Positioning speed: 12000mm/s Writing speed: 600cps Step response time (full stroke 1%): 210us Step response time (full stroke 10%): 710us Tracking error: ≤138us Accuracy and error Linearity: 99.9% Repeatable positioning accuracy:＜8μRad. Gain error:＜5mRad. Zero offset (batch origin error): ＜5mRad. Long-term drift (continuous operation for 8 hours): ＜0.5mRad. Proportional drift: ＜40PPM/℃ Zero drift:＜15μRad./℃ | |
